Troubleshooting Snapshots

During the capture process, Chromatic continually takes screenshots until it either reaches the maximum allowed timeout or it captures two matching screenshots, indicating that the page has settled. This ensures the snapshot is consistent and that UI is in its final state.

Image and font rendering can be tricky. Resources that load from unpredictable or flaky sources may not load in time (15s) to capture. Work around this by:

• Ensure fonts load reliably fast in Chromatic
• Ensure resources load reliably fast in Chromatic
• Serve resources as static files (this also improves your test speed)
• Using a placeholder service.

If your resources are behind a firewall, whitelist our domain so we can load your resources.

The srcset attribute is a useful mechanism that provides the browser with a list of potential images to display, based on specified conditions such as media queries.

In most cases, Chromatic will capture the correct image from the srcset list. However, if multiple tests list the same image in their respective srcset lists, browser cache issues can result in inconsistent snapshots.

In situations like this, the best workaround is to make the srcset URLs unique for each test by adding a random query parameter value.

For instance, one test could have a srcset with a query parameter of ?cachebuster=1714593641616.

<picture>
  <source
    sizes="(max-width: 768px) 100vw, 50vw"
    type="image/webp"
    srcset="
​      https://placehold.co/384x384.webp?cachebuster=1714593641616 384w,
​      https://placehold.co/640x640.webp?cachebuster=1714593641616 640w,
​      https://placehold.co/750x750.webp?cachebuster=1714593641616 750w"
  />
  <img
    alt="Alt text"
    loading="eager"
    width="1500"
    height="1500"
    decoding="async"
    sizes="(max-width: 768px) 100vw, 50vw"
    src="https://placehold.co/3840x3840.jpeg"
    style="color: transparent;"
  />
</picture>

If another test uses the same images, they can alter the query parameter in the URL to ?currenttime=1714593641620.

<picture>
  <source
    sizes="(max-width: 768px) 100vw, 50vw"
    type="image/webp"
    srcset="
​      https://placehold.co/384x384.webp?currenttime=1714593641620 384w,
​      https://placehold.co/640x640.webp?currenttime=1714593641620 640w,
​      https://placehold.co/750x750.webp?currenttime=1714593641620 750w"
  />
  <img
    alt="Alt text"
    loading="eager"
    width="1500"
    height="1500"
    decoding="async"
    sizes="(max-width: 768px) 100vw, 50vw"
    src="https://placehold.co/3840x3840.jpeg"
    style="color: transparent;"
  />
</picture>

Any query parameter name can be used, just so long as the value is unique to each test.

Emojis are handled by your operating system’s emoji font. Most OSs have a different emoji font and those fonts tend to change over time. For example, if you view a story on a Mac you’ll get Apple’s set of emojis.

Chromatic captures Chrome and Firefox snapshots in a Linux environment. It includes a common set of emojis used by most systems. Those emojis will likely look different from emojis on a consumer OS like Mac or Windows. Unfortunately, there’s no workaround available at this time.

Videos are interactive and time-based which introduces inconsistencies in snapshots. Chromatic hides videos by default to prevent false positives. You’ll see the poster image (if specified) or a blank space where the video is supposed to render.

Most likely, you are calling into window.parent somewhere in your code. As we serve your test preview iframe inside our www.chromatic.com domain, this leads to an x-origin error as your code doesn’t have access to our frame (with good reason!).

Generally speaking it is a good idea to wrap calls like that in a try { } catch in case the code is running in a context where that’s not possible (e.g., Chromatic).

Make sure there are no elements inadvertently cutting off content through the use of overflow or height styles.

For elements that have relative height styles based on the size of the viewport (such as height: 100vh), all content nested under that element will show up in a screenshot unless either overflow: hidden or overflow: scroll is used to hide what is outside of that element (and therefore outside of the viewport).

When Chromatic takes a screenshot for an element that has a viewport-relative height as well as styling to hide/scroll the overflow, a default viewport height of 900px will be used. This default is only used when we can’t detect a “natural” height for the outermost DOM element (root ancestor), for instance, in the case of scrollable divs.

To set the height, you can add a decorator for stories that wraps them in a container with a fixed height:

// MyComponent.stories.js|jsx

import { MyComponent } from "./MyComponent";

export default {
  component: MyComponent,
  title: "Example Story",
  decorators: [
    (Story) => (
      <div style={{ margin: "3em" }}>
        <Story />
      </div>
    ),
  ],
};

Scrollable divs constrain the height of their children. Change the height of the scrollable div to ensure all content fits. It’s not possible for Chromatic to infer how tall scrollable divs are intended to be.

If you use an “animateIn” effect set delay to ensure we snapshot when the animation completes.

If your component infers its dimensions from the layout of the surrounding DOM elements (e.g., it’s a modal that uses position:fixed), you’ll need to set the height of that component’s stories using a decorator.

// MyComponent.stories.js|jsx

import { MyComponent } from "./MyComponent";

export default {
  component: MyComponent,
  title: "Example Story",
  decorators: [
    (storyFn) => (
      <div style={{ width: "1200px", height: "800px" }}>
        This is a decorator for modals and such {storyFn()}
      </div>
    ),
  ],
};

/*
 *👇 Render functions are a framework-specific feature to allow you control over how the component renders.
 * See https://storybook.js.org/docs/api/csf#custom-render-functions
 * to learn how to use render functions.
 */
export const StoryWithDimensions = {
  render: () => <MyComponent />,
};

If your component infers its dimensions from the layout of the surrounding DOM elements (e.g., it’s a modal that uses position:fixed), you can set the height of that component’s stories using a decorator.

// MyComponent.stories.js|jsx

import { MyComponent } from "./MyComponent";

export default {
  component: MyComponent,
  title: "Example Story",
  decorators: [
    (storyFn) => (
      <div style={{ width: "1200px", height: "800px" }}>
        This is a decorator for modals and such {storyFn()}
      </div>
    ),
  ],
};

/*
 *👇 Render functions are a framework-specific feature to allow you control over how the component renders.
 * See https://storybook.js.org/docs/api/csf#custom-render-functions
 * to learn how to use render functions.
 */
export const StoryWithDimensions = {
  render: () => <MyComponent />,
  args: {},
};

Yes, check out the Chromatic’s modes feature is simplifies the process of visually testing your stories with different global configs such as themes. Check out the Themes in modes guide to get started.

Blank snapshots are often caused by:

• An “animateIn” effect—If your component use an “animateIn” effect set delay to ensure we snapshot when the animation completes.

• Position:fixed—Fixed position elements may depend on viewport size but do not have dimensions themselves. Wrap your component in an element whose height and width are defined.

Learn more about debugging snapshots.

By default, Chromatic’s diffing algorithm skips the DOM elements marked with either a .chromatic-ignore CSS class or data-chromatic="ignore" attribute.

However, if you’re using this functionality but notice the incoming changes are still being captured. In that case, you’ll need to ensure that both the baseline and new snapshots retain the same dimensions (e.g., width, height, and relative positioning).

Certain UI libraries like Material calculate the dimensions of each tab by measuring the rendered width of the tab’s children using JavaScript (for example, via getBoundingClientRect()).

However, this can lead to inconsistent snapshots in cases where you load a custom font. Fonts affect the dimensions of text within tabs. Since custom fonts can load before, during, or after the tab component itself loads, the dimensions calculated by the tab component can also vary.

The solution we recommend is to use a <link rel="preload"> in your .storybook/preview-head.html to preload the font before the story renders. This ensures that the dimensions of the contents inside of the tab component remain consistent when measured.

Certain charting libraries like Highcharts measure the available space to determine where elements should be laid out.

But this can lead to inconsistent snapshots in cases where you load a custom font. Fonts can load before, during, or after the component itself loads. And different fonts have different dimensions when rendered.

The solution we recommend is to use a <link rel="preload"> in your .storybook/preview-head.html to preload the font before the story renders. This ensures that the dimensions and position of the fonts inside of the graph component remain consistent.

For stories, Chromatic relies on the “natural” height of your component’s outermost DOM element (using Storybook’s #storybook-root element in version 7 or higher or the #root element for previous versions) to determine snapshot dimensions. As portals render outside of Storybook’s DOM tree, Chromatic cannot auto-detect their dimensions, which can lead to cut-off snapshots.
